¤ Profile


( formerly called fluidyne Products) was started in 1973 by Mr.M.H.Y.Kazi an  Ex-Vickers, the only  gauge Isolator valve manufacturer company in INDIA. Subsequently developing many high pressure precision hydraulic valves & accessories.

was first to develop & manufacture oil injection equipment pump used for bearing mounting & dismounting in INDIA For SIBCO (SKF bearing division).

Serving the best quality valves in Hydraulic to the pioneers like YUKEN India Ltd, BOSCH REXROTH  India Ltd., Vickers India Ltd, Windsors M/cs, SKF India Ltd., PARKER HANNIFFIN India & Many other reputed dealers all over India.

manufactures valves that consistently exceed our customers expectations, for productivity, reliability & affordability. To control costs & component availability, while providing our customer with the best value in industry, we carry out all critical processes in-house.

manufactures valves possible for the broadest market & offer them at competitive prices.




  ¤ Products


Single Station Gauge Isolators

Model - FGI 01 (Push-To-Read)
This push-to-read Gauge Isolator is designed for use with pressure gauges to prevent damage from shocks.The unit automatically vents the gauge to tank when a gauge reading is not required, and considerable saving can be obtain on the life of the gauge and, the most important factor, also preserving the accuracy of the gauge. This standard unit is designed basically for panel mounting. The unit has a basic high grade alloy C.I. body with hardened alloy steel spool, and is suitable for working pressure up to 3000 psi) By using this type of Gauge Isolator, guaranteed savings are ensured on the life of your Pressure Gauge.

Model - FGI- 01-L (Push-To-Lock)
This is the Lockable (Detent) type of Push-to-read Gauge Isolator. In addition to the features of FGI 01 model, this isolator can be locked in READ position by  a twist of the knob after pushing. This model finds application wherever pressure reading is required for a considerable period of time

Technical Specifications :-

  Connections :

  1/4"  B.S.P. female (Port P,G,T)

  Max. Working Pr. :

  3000 psi (210 bar)

  Weight  :

  0.6 kg

  Mounting  :

Max.8 mm panel thicknesss in Ø 31mm Panel


Multi-Station Gauge Isolator Valve

Multi Station Pressure Gauge Isolators may replace number of pressure gauge and shut-off valves needed to read pressure at various points in multi pressure hydraulic system. The pressure can be read on a single pressure gauge by indexing the knob. Also, it eliminates pressure lock upon pressure gauges, reducing damage and increasing their life considerably.

Model : FGI - 05 ( Indexing Type)
In case of systems having working pressure above 100 kg./sq. cm, If Symmetrical connection are not possible, then the use of model FGI - 05 is recommended. In this model only five pressure line connection can be given to the isolator, and sixth position which is marked ' O' is used for venting pressure gauge to tank. In both models, the unwanted ports are to be plugged with 1/4" BSP plugs and copper sealing rings. The isolator can be mounted with four allen screws M6, after removal of graduated dial.

Model : FGI - 06 ( Push - To - Read )
In this model maximum six pressure line connection
can be given. For reading the desired line pressure, index and push knob. When knob is released, pressure gauge is automatically vented to tank. When using this model, if there is a working pressure above 150 kg/sq. cm then the pressure connection must be done symmetrically.



  ¤ Clients
Clients

YUKEN India Ltd.
BOSCH Rexroth India Ltd.
Vickers (I) Ltd.
Windsor Machines Ltd.
Parker Hanniffin India Ltd.
SKF India Ltd


Many Reputed Dealers & End - users

ASM Hydraulics, Pune
Abishek Enterprise, Pune
Arun Hydraulics, Ahmedabad
Bell Hydromatics, Mumbai
Chandra Hydraulics, Delhi
Fluid Logic Systems, Ahmedabad
Fluid Control & Allied Products, Bangalore
G.S. Hydraulics, Mumbai
Hiflex Hydraulics, Ahmedabad
Hy-tech Hydraulics, Bangalore
Hydrocontrol, New Delhi
Khanna Hydraulics, Hyderabad
Kazaf Co., Mumbai
Super-tech Crane Bel Ghaziabad

  ¤ Contact


Address :

  42, Vadhani Industrial Estate, L.B.S.Marg, Ghatkopar (W),
  Mumbai - 400086, Maharashtra, INDIA.

Contact Person :

 MR. ZAKI M. KAZI

  Tel. :

  91-022-25001286

  Cell  :

  9920774959

  Email :

 response@fenertools.com
